TASCAM SB-16D 16-In/16 Out Dante Stage Box

16-in/16-out Dante-enabled stage box and interface.

Offering the same performance and hardware quality as Sonicview recording and live mixers, the TASCAM SB-16D Dante-networked 16-in/16-out stage box offers all the advantages of Dante networking, combined with seamless integration with Sonicview mixers. The stage box can be used as a floor stage box or rack mounted, and multiple stage boxes can be used simultaneously in a Dante network. Large ensembles and extensive installed Dante systems can be easily accommodated using the SB-16D’s 16 XLR mic/line inputs and 16 XLR line outputs. Need more I/O? Simply network multiple SB-16Ds. The mic/line inputs are extremely quiet, achieving a -128 dBu EIN with a +32 dBu maximum input level. Each input channel has +48V phantom power and an SIG OL LED for input-level monitoring. Each line output also is equipped with SIG OL LEDs. The SB-16D supports Dante Domain Manager in addition to AES67 and SMPTE 2110 interoperability. Two Dante ports equipped with etherCON-compatible Dante connectors enable redundant streams with robust connections. For additional system reliability, a DC power input is provided that supports a redundant power supply (not included). Whether you want a networked floor box for stage use, or rack-mounted inputs for recording and broadcast studios and commercial installs, the SB-16D provides the flexibility you need.
Features
Redundant Dante supportEquipped with etherCON-compatible connectorsDante Domain Manager supportAES67 interoperabilitySMPTE 2110 interoperability16 XLR mic/line inputs with +48 phantom power and SIG OL LED input signal/overload indicators16 XLR line outputs with SIG OL LED output signal indicatorsUp to 96 kHz sampling and 32-bit precisionSupports both floor installation and 3U rack-mountingControllable from connected Sonicview mixersRemote control and offline editing using TASCAM IO Control app for macOS, Windows and iPadOS
Order the SB-16D Dante Stage Box today.
SB-16D 16-In/16 Out Dante Stage Box Specifications:
Connector: XLR-3-31 equivalent (1: GND, 2: HOT, 3: COLD)
Input impedance: 5.0k? or more
Maximum input level: +32dBu (TRIM minimum, PAD: on), +12dBu (TRIM minimum, PAD: off)
Minimum input level: -42dBu (TRIM max, PAD: on), -62dBu (TRIM max, PAD: off)
Phantom power: +48V supply possible
