Allen & Heath ME-500 Personal Monitor Mixer
Description
Description
Lightweight and powerful personal mixer.
ME-500 is a powerful mixing solution that’s quick to set up and easy to learn. The ME-500 personal mixer’s intuitive hands-on controls and crisp visual display make it easy for musicians to build and control their own monitor mixes. With plug ‘n’ play setup and self-sufficient musicians, ME-500 is also a massive time-saver for the audio engineer.With ME-500 there’s no time-consuming configuration of individual units. The first 16 mono / stereo channels and / or mixes assigned from the mixer will be automatically mapped to ME-500’s 16 select keys, so it’s fast and simple to deploy personal mixers in pressured situations such as festivals.User PresetsLevels, pan and mutes can all be stored and recalled at the touch of a button. Presets can be saved to USB and easily transferred to different ME-500s. For budget-conscious or low channel count applications, or for more impromptu scenarios where the engineer and artists have very limited soundcheck time (festivals being the typical example), ME-500 is a great solution for getting the show up and running with minimum fuss.ME-500 mixers can be directly connected to any available ME, SLink, dSnake or Monitor port in an Allen & Heath digital mixing system. Multiple ME-1 and ME-500 mixers can be daisy-chained with all mixers powered via external PSU.The ME-U hub can be connected to any available ME, SLink, dSnake or Monitor port in an Allen & Heath digital mixing system. ME-500 mixers connected directly to the ME-U are powered via PoE. Additional and ME-500 mixers can be daisy-chained and powered via external PSU. Multiple ME-U hubs can be daisy-chained together if more than 10 ports are required.ME 3rd Party OptionsThe ME-U hub can be fitted with a Dante or MADI option card enabling the connection of 3rd party digital mixing systems. ME-500 mixers connected directly to the ME-U are powered via PoE. Additional ME-500 mixers can be daisy-chained and powered via external PSU. Multiple ME-U hubs can be daisy-chained together if more than 10 ports are required.
Features
16 Mono / stereo inputs with level and pan controlMaster 2 band EQ and LimiterAutomatic key assignment8 User presets3.5mm and 1/4” headphone outputsSolo and Mute keysMains or PoE poweredDaisy chain or use standard PoE Ethernet hubs
Lightweight, compact and powerful.
ME-500 Personal Monitor Mixer Specifications:
AD/DA Conversion: 24-bit Delta/Sigma, 48kHz
PoE Requirements: 802.3af (15.4W at source) or 802.at (25.5W at source)
Ext PSU: IN: 100-240V AC , 50/60Hz / OUT: 12V DC , 1.25A
Frequency Response: 10Hz to 20kHz (+0/-1dB)
Residual Output Noise: -95dBu
Headphone Out: 300mW + 300mW into 100? load
230 x 160 x 70 mm (9” x 6.3” x 2.7”) x 1.1kg (2.4lbs)
